Technical specifications
Metric
Imperial
WORKING CAPACITY
Floorplates size (LxWxH)
1100x750 mm43,31x29,53 in
Column distance
1220 mm48,03 in
Max distance beween plates
985 mm38,78 in
Min discance between plates
85 mm3,35 in
Max weight on lower plate
5000 Kg
Max weight on upper plate
2000 Kg
Max closing strenght
200/400 kN
Max opening strenght
100/200 kN
Upper table overturning
180 °
FEEDS
Approach speed
0-50 mm/sec
Working speed
0-50 mm/sec
Return speed
65 mm/sec
EXTRA
Colpo d’ariete
Yes
Total power supply
7,5/11 Kw
Machine weight
5000 kg
Floor space
2900x1800x3300 mm114,17x70,87x129,92 in
