Technical specifications
Metric
Imperial
WORKING CAPACITY
Floorplates size (LxWxH)
over 1000x1200 / under 900x1280 mmover 39,37x47,24 / under 35,43x50,39 in
Column distance
1250 mm49,21 in
Max distance beween plates
1100 mm43,31 in
Max closing strenght
4000 kN
Upper table overturning
180 °
Max weight on lower plate
7000 Kg
Lower table rotation
70 °
EXTRA
Machine weight
8.000 kg
Total power supply
7,5 Kw
Floor space
3720x2030x3595 mm146,46x79,92x141,54 in
Wax injector
Yes
Colpo d’ariete
Yes
