Category
Milling machine
Type
mobile column
Made
Model
MX1000
Capacity
6000x1700x1000 mm236,22x66,93x39,37 in
Technical specifications
Metric
Imperial
WORKING CAPACITY
Longitudinal (X)
6000 mm236,22 in
Vertical (Y)
1700 mm66,93 in
Cross RAM (Z)
1000 mm39,37 in
Axes support
guide a rulli
CNC
CNC
Heidenhain TNC430M
Drives
Siemens SIMODRIVE611
SPINDLE
Spindle power
28/35 Kw
Gearbox
ZF
Rotating speed
0-4000 Rpm
Taper
ISO50
FEEDS
Rapid X
25 m/min984,25 ipm
Rapid Y
25 m/min984,25 ipm
Rapid Z
25 m/min984,25 ipm
X
15 m/min590,55 ipm
Y
15 m/min590,55 ipm
Z
15 m/min590,55 ipm
ATC
Positions
40
Max tool diameter
150 mm5,91 in
Max diam with free adiacent space
250 mm9,84 in
Max tool lenght
500 mm19,69 in
Max tool weight
20 Kg
Tool taper
ISO50
Position
a catena sulla colonna
FIXING TABLE
Floorspace (LxWxH)
8100x1100 mm318,90x43,31 in
Capacity
4000 Kg/mq
HEAD 1
Type
Kosmo4000
Available upon request
Yes
Spindle taper
ISO50
A axis
3 °
C axis
2,5 °
Max speed
4000 Rpm
Max power
35 Kw
Coolant
interno/esterno
TABLE 1
Available upon request
No
EXTRA
Available in stock
si
Chip conveyor
2 evacuatori longitudinali
Availability
pronta
Maintenance & Use books
Yes
Electrical drawings
Yes
CE Certification
Yes
Housing
perimetrale
Total power supply
45 Kw
Machine total weight
43200 Kg
Mobile operator platform
si
