Category
Milling machine
Type
mobile column
Made
Model
CS88G
Capacity
4300x1700x1000 mm169,29x66,93x39,37 in

Technical specifications

Metric Imperial
WORKING CAPACITY
Longitudinal (X)
4300 mm169,29 in
Vertical (Y)
1700 mm66,93 in
Cross RAM (Z)
1000 mm39,37 in
SPINDLE
Spindle power
24 Kw
Rotating speed
≈2000 Rpm
Taper
ISO50
FEEDS
Rapid X
10 m/min393,70 ipm
Rapid Y
10 m/min393,70 ipm
Rapid Z
10 m/min393,70 ipm
HEAD 1
C axis
360x1 °
A axis
manuale °
Spindle taper
ISO50
Max speed
≈2000 Rpm
Notes
birotativa automatica parte posteriore
TABLE 1
Surface
6000x1000 mm236,22x39,37 in
CNC
CNC
SELCA 3045
The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy cannot be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!
