Technical specifications
Metric
Imperial
WORKING CAPACITY
Centres distance
2000 mm78,74 in
Centres height
600 mm23,62 in
Max diameter on the bed
1240 mm48,82 in
Max swing on saddle
790 mm31,10 in
Bar passage
150 mm5,91 in
BED
Bed width
670 mm26,38 in
Max weight between centres
8000 Kg
Max weight on steadies
10000 Kg
HEAD
Spindle power
35 Kw
Spindle speed
800 Rpm
Spindle taper
ASA11”
TAILSTOCK
Quill diameter
115 mm4,53 in
Quill stroke
380 mm14,96 in
Taper
MK6
EXTRA
Digital read out (DRO)
SI
Closed steadies
SI
Platform
SI
Maintenance & Use books
Yes
Electrical drawings
Yes
Protections
SI
Available in stock
SI
Available under power
SI
