Technical specifications
Metric
Imperial
WORKING CAPACITY
Centres height
410 mm16,14 in
Centres distance
2000 mm78,74 in
Max swing on saddle
550 mm21,65 in
Max swing in the gap
1000 mm39,37 in
Bar passage
155 mm6,10 in
HEAD
Spindle taper
CL 11
Notes
motore in c.c.: inverter sul mandrino con potenziometro
Spindle speed
1000 Rpm
TURRET
Notes
Tipo A
BED
Bed width
500 mm19,69 in
EXTRA
Autocentering chuck
diam. 380mm
Platform
diam. 800 mm
The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy cannot be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!
