Category
Turning Machine
Type
Center
Made
Model
T30 300x2000mm
Capacity
625x2000x105 mm24,61x78,74x4,13 in
Technical specifications
Metric
Imperial
WORKING CAPACITY
Centres distance
2000 mm78,74 in
Centres height
300 mm11,81 in
Longitudinal (Z)
2000 mm78,74 in
Cross (X)
450 mm17,72 in
Max turning lenght
2000 mm78,74 in
Max diameter on the bed
625 mm24,61 in
Max swing on saddle
325 mm12,80 in
Bar passage
105 mm4,13 in
BED
Bed width
450 mm17,72 in
Guide-ways number
2
Max weight between centres
3000 Kg
Max weight on steadies
4000 Kg
EXTRA
Electrical drawings
Yes
Availability
pronta
Available under power
si
