Category
Milling machine
Type
T type
Made
Model
LEM T10
Capacity
3000x2000x1000+1200 mm118,11x78,74x39,37+47,24 in

Technical specifications

Metric Imperial
WORKING CAPACITY
Longitudinal (X)
3000 mm118,11 in
Vertical (Y)
2000 mm78,74 in
Cross column (Z)
1000 mm39,37 in
Ram (V)
1200 mm47,24 in
TABLE 1
Capacity
20.000 Kg
Surface
3500x1300 mm137,80x51,18 in
HEAD 1
Max speed
3000 Rpm
Type
Birotativa automatica TU360
Spindle taper
ISO50
A axis
360x1 °
C axis
360x1 °
CNC
CNC
Heidenhain TNC430
SPINDLE
Rotating speed
3000 Rpm
Taper
ISO50
EXTRA
CE Certification
Yes
Chip conveyor
si
The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy cannot be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!
