Category
Milling machine
Type
T type
Made
Model
AREA T 10
Capacity
3000x1750x2000 mm118,11x68,90x78,74 in

Technical specifications

Metric Imperial
WORKING CAPACITY
Longitudinal (X)
3000 mm118,11 in
Vertical (Y)
2000 mm78,74 in
Cross column (Z)
1020 mm40,16 in
Ram (V)
1030 mm40,55 in
FEEDS
Rapid X
12 m/min472,44 ipm
Rapid Y
12 m/min472,44 ipm
Rapid Z
12 m/min472,44 ipm
TABLE 1
Surface
1500x1500 mm59,06x59,06 in
Capacity
15000 Kg
HEAD 1
Spindle taper
ISO50
Max speed
3000 Rpm
SPINDLE
Spindle power
22 Kw
Rotating speed
0-3000 Rpm
CNC
CNC
NUM 760
