Category
Milling machine
Type
Bed type
Made
Model
SL90/2000 TR
Capacity
2000x1100x1000 mm78,74x43,31x39,37 in
Technical specifications
Metric
Imperial
WORKING CAPACITY
Longitudinal (X)
2000 mm78,74 in
Vertical (Y)
1100 mm43,31 in
Cross RAM (Z)
1000 mm39,37 in
CNC
CNC
SELCA 3045PD
SPINDLE
Spindle power
22/33 Kw
Rotating speed
5000 Rpm
Taper
ISO50 DIN69871
FEEDS
Rapid X
10 m/min393,70 ipm
Rapid Y
10 m/min393,70 ipm
Rapid Z
10 m/min393,70 ipm
TABLE 1
Surface
1250x1000 mm49,21x39,37 in
Accuracy (B axis)
360.000 °
Capacity
7.000 Kg
Available upon request
No
HEAD 1
Type
TU600
Spindle taper
ISO50 DIN69871
A axis
2x180 °
C axis
144x2,5 °
Max speed
5000 Rpm
Max power
33 Kw
Available upon request
No
ATC
Positions
20
Max tool diameter
125 mm4,92 in
Max diam with free adiacent space
250 mm9,84 in
Max tool lenght
350 mm13,78 in
FIXING TABLE
Available upon request
No
EXTRA
Housing
protezioni frontali scorrevoli
Chiller
si
Machine total weight
≈15.000 Kg
Floor space
4600x4900x3300 mm181,10x192,91x129,92 in
Chip conveyor
2
Workpiece touch probe
si
Filtration unit
coolant tank with paper filter
Availability
pronta
CE Certification
No
Available in stock
SI
Tooling included
volantino remotato
Maintenance & Use books
Yes
