Technical specifications
Metric
Imperial
WORKING CAPACITY
Longitudinal (X)
680 mm26,77 in
Cross RAM (Y)
350 mm13,78 in
Max grinding lenght
680 mm26,77 in
Spindle nose axis - table distance
380 mm14,96 in
TABLE
Surface
600X300 mm23,62X11,81 in
Cross speed
2-30
FEEDS
Automatic Vertical
SI mm/minSI ipm
Cross
SI mm/minSI ipm
WHEEL
Max wheel diameter
350 mm13,78 in
Wheel band thickness
50 mm1,97 in
WHEEL SPINDLE
Rotating speed
1540 Rpm
EXTRA
Total power supply
8,8 Kw
