Category
Grinding Machine
Type
Surface
Made
Model
RTL 1200 CN
Capacity
1200x700 mm47,24x27,56 in
Technical specifications
Metric
Imperial
WORKING CAPACITY
Longitudinal (X)
1200 mm47,24 in
Vertical (Z)
400 mm15,75 in
Cross Table (Y)
700 mm27,56 in
TABLE
Surface
1250x700 mm49,21x27,56 in
Cross speed
1-38
Rotating speed
1450 Rpm
MAGNETIC TABLE
Available upon request
Yes
Surface
1200x600 mm47,24x23,62 in
CNC
Notes
DIAMANTATURA CON CONPENSAZIONE AUTOMATICA/BILANCIATORE MOLA ELETTRONICO
CNC
SIDAC CN
WHEEL SPINDLE
Spindle power
15 Kw
Rotating speed
1450 Rpm
WHEEL
Wheel band thickness
70 mm2,76 in
Max wheel diameter
400 mm15,75 in
Hole diameter
127 mm5,00 in
EXTRA
Total power supply
15 Kw
Machine total weight
8000 Kg
Floor space
4000X3500X2100 mm157,48X137,80X82,68 in
Tooling included
PIANO MAGNETICO ELETTRONICO
Automatic dresser
Yes
Filtration unit
FILTRO A CARTA E SEPARATORE MAGNETICO
Electrical drawings
Yes
CE Certification
Yes
Maintenance & Use books
Yes
Housing
COMPLETA
Mist extractor
SI
Availability
PRONTA
Available in stock
SI
Digital read out (DRO)
CN
