Technical specifications
Metric
Imperial
WORKING CAPACITY
Cross RAM (Y)
310 mm12,20 in
Vertical (Z)
300 mm11,81 in
Max grinding thickness
300 mm11,81 in
Max grinding width
500 mm19,69 in
Spindle nose axis - table distance
450 mm17,72 in
TABLE
Diameter
600 mm23,62 in
MAGNETIC TABLE
Surface
ø600 mmø23,62 in
EXTRA
Machine total weight
3850 Kg
Floor space
1700x1600x2100 mm66,93x62,99x82,68 in
Availability
pronta
Available in stock
si
