Category
Grinding Machine
Type
ID/OD
Made
Model
518 UA
Capacity
ø355x500 mmø13,98x19,69 in
Technical specifications
Metric
Imperial
WORKING CAPACITY
Centres distance
500 mm19,69 in
Centres height
180 mm7,09 in
Max grinding diameter
355 mm13,98 in
Longitudinal (Z)
500 mm19,69 in
Max internal diameter
140 mm5,51 in
Max internal depth
160 mm6,30 in
Max grinding lenght
500 mm19,69 in
RIGHT WHEEL
Wheel band thickness
50/70 mm1,97/2,76 in
Max wheel diameter
450 mm17,72 in
Hole diameter
127 mm5,00 in
TAILSTOCK
Drive
IDRAULICO
Taper
CM3”
TABLE
Stroke
4-500 mm0,16-19,69 in
Cross speed
100-7000 mm/min3,9370-275,5900 ipm
Tilt
10 °
FEEDS
Cross
0,01-1,8 mm/min0,0004-0,0709 ipm
WHEELHEAD
External spindle power
7,5 Kw
External spindle speed
1275/1450 Rpm
Internal spindle power
1,5 Kw
Transmission
cinghia
WORKPIECE HEAD
Spindle power
0,75 Kw
Rotating speed
20-355 Rpm
Taper
CM4”
Tilt
90 °
EXTRA
Tooling included
APPARECCHIO PER INTERNI DISPONIBILE
Machine total weight
3200 Kg
Floor space
3050x2000x2000 mm120,08x78,74x78,74 in
Digital read out (DRO)
2 assi
Available in stock
si
Diametral probe
Yes
Total power supply
7,5 Kw
