Technical specifications
Metric
Imperial
WORKING CAPACITY
Max grinding diameter
360 mm14,17 in
Max grinding lenght
500 mm19,69 in
Centres distance
500 mm19,69 in
Centres height
180 mm7,09 in
TABLE
Tilt
+/- 6 °
Max workpiece weight
70 Kg
Stroke
500 mm19,69 in
WORKPIECE HEAD
Taper
4
Rotating speed
35/310 Rpm
Tilt
+30/+90 °
WHEELHEAD
Accuracy (B axis)
+30/-90 °
External spindle speed
1500 Rpm
External spindle power
5,5 Kw
LEFT WHEEL
Wheel band thickness
40 mm1,57 in
Max wheel diameter
410 mm16,14 in
Hole diameter
127 mm5,00 in
TAILSTOCK
Taper
mk3
CNC
Measuring system
visualizzatore
EXTRA
Digital read out (DRO)
si
