Category
Grinding Machine
Type
ID/OD
Made
Model
R5
Capacity
500X130 mm19,69X5,12 in

Technical specifications

Metric Imperial
WORKING CAPACITY
Centres distance
500 mm19,69 in
Centres height
130 mm5,12 in
Max grinding diameter
260 mm10,24 in
FEEDS
Automatic Vertical
SI mm/minSI ipm
LEFT WHEEL
Wheel band thickness
50 mm1,97 in
Max wheel diameter
406 mm15,98 in
Hole diameter
127 mm5,00 in
WORKPIECE HEAD
Speed regulation
VARIABILE C/C
EXTRA
Digital read out (DRO)
SI
Filtration unit
SI
Maintenance & Use books
Yes
Electrical drawings
Yes
Manual dresser
Yes
Availability
PRONTA
Available in stock
SI
