Category
Grinding Machine
Type
Cylindrical
Made
Model
1518 UM
Capacity
1500 x 180 mm59,06 x 7,09 in
Technical specifications
Metric
Imperial
WORKING CAPACITY
Centres distance
1500 mm59,06 in
Centres height
180 mm7,09 in
Cross (X)
310 mm12,20 in
Max grinding lenght
1500 mm59,06 in
Max grinding diameter
355 mm13,98 in
Longitudinal (Z)
1500 mm59,06 in
Notes
Possibilità lavorazione per interni
TABLE
Cross speed
0,1-5 mm/min0,0039-0,1969 ipm
Max workpiece weight
250 Kg
Tilt
+/-9 °
FEEDS
Cross
0,1/4 mm/min0,0039/0,1575 ipm
WHEELHEAD
External spindle power
5,5 Kw
External spindle speed
1235/1450 Rpm
LEFT WHEEL
Wheel band thickness
80 mm3,15 in
Max wheel diameter
500 mm19,69 in
Hole diameter
127 mm5,00 in
WORKPIECE HEAD
Spindle power
1,1 Kw
Rotating speed
16-500 Rpm
Speed regulation
Variazione progressiva
Tilt
+/-90 °
Taper
MK4
TAILSTOCK
Quill diameter
35 mm1,38 in
Taper
MK4
Drive
Idraulico a pedale + leva manuale
