Category
Turning Machine
Type
Teach in
Made
Model
URSUS TC 600
Capacity
600x2000x105 mm23,62x78,74x4,13 in
Technical specifications
Metric
Imperial
WORKING CAPACITY
Max bar working diameter
105 mm4,13 in
Max swing on the bed
600 mm23,62 in
Max swing on saddle
365 mm14,37 in
Max working lenght
2000 mm78,74 in
Guide-ways number
2
CNC
CNC
ECS 2400
SADDLE
X rapid feed
10 mm/min0,3937 ipm
Z rapid feed
12 mm/min0,4724 ipm
X stroke
380 mm14,96 in
Z stroke
2000 nn
MAIN SPINDLE
Max rotation speed
10-2200 rpm
Spindle nose
CL8”
Spindle hole
105 mm4,13 in
Max power
9/13 Kw
Chuck diameter
315 mm12,40 in
Max torque
1650 Nm
EXTRA
Total power supply
15 Kw
Machine total weight
6000 Kg
Floor space
4800x1800 mm188,98x70,87 in
Autocentering chuck
3-jaws 315mm
Maintenance & Use books
Yes
Electrical drawings
Yes
CE Certification
Yes
Protections
carenatura integrale
Availability
pronta consegna
Available in stock
Yes
Available under power
Yes
Fixed toolholders
portabareni
