Technical specifications
Metric
Imperial
WORKING CAPACITY
Floorplates size (LxWxH)
750x1100 mm29,53x43,31 in
Column distance
1200 mm47,24 in
Max distance beween plates
985 mm38,78 in
Min discance between plates
85 mm3,35 in
Max weight on upper plate
5000 Kg
Max closing strenght
400 kN
Max opening strenght
200 kN
Lower table overturning
70 °
Upper table overturning
180 °
Notes
STAMPO MAX SUI PIANI 980x900
Max weight on lower plate
2000 Kg
FEEDS
Approach speed
45 mm/sec
Return speed
55 mm/sec
EXTRA
Total power supply
15 Kw
Machine weight
10000 kg
Floor space
3000x2300x3600 mm118,11x90,55x141,73 in
Colpo d’ariete
Yes
