Technical specifications
Metric
Imperial
WORKING CAPACITY
Floorplates size (LxWxH)
1400x1200 mm55,12x47,24 in
Column distance
1300x1540 mm51,18x60,63 in
Max distance beween plates
1100 mm43,31 in
Min discance between plates
250 mm9,84 in
Upper table overturning
100 °
Max weight on lower plate
10000 Kg
Max weight on upper plate
5000 Kg
Max closing strenght
1000 kN
Max opening strenght
220 kN
FEEDS
Approach speed
50-65 mm/sec
Working speed
8 mm/sec
Return speed
35-50 mm/sec
EXTRA
Total power supply
7,5 Kw
Machine weight
14000 kg
