Category
Grinding Machine
Type
Surface
Made
Model
540
Capacity
483x171x241 mm19,02x6,73x9,49 in
Technical specifications
Metric
Imperial
WORKING CAPACITY
Longitudinal (X)
483 mm19,02 in
Cross Table (Y)
171 mm6,73 in
Spindle nose axis - table distance
50-330 mm1,97-12,99 in
Max grinding lenght
483 mm19,02 in
Vertical (Z)
280 mm11,02 in
Max grinding thickness
240 mm9,45 in
TABLE
Surface
650x160 mm25,59x6,30 in
WHEEL
Wheel band thickness
31,8 mm1,25 in
Max wheel diameter
177,8 mm7,00 in
Hole diameter
12,7 mm0,50 in
WHEEL SPINDLE
Spindle power
1,5 Kw
Rotating speed
2800 Rpm
EXTRA
Floor space
1200x950x1700 mm47,24x37,40x66,93 in
Machine total weight
1500 Kg
Tooling included
Optidress
The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy cannot be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!
