Category
Grinding Machine
Type
Surface
Made
Model
1400 AR
Capacity
635x203x408 mm25,00x7,99x16,06 in
Technical specifications
Metric
Imperial
WORKING CAPACITY
Longitudinal (X)
635 mm25,00 in
Vertical (Z)
279 mm10,98 in
Cross Table (Y)
203 mm7,99 in
Spindle nose axis - table distance
83-360 mm3,27-14,17 in
TABLE
Surface
610x178 mm24,02x7,01 in
Cross speed
3-21
FEEDS
Automatic Vertical
0,001-0,006 mm/min0,0000-0,0002 ipm
Cross
0,178-1,78 mm/min0,0070-0,0701 ipm
WHEEL SPINDLE
Spindle power
1,5 Kw
Rotating speed
2570 Rpm
Support
cuscinetti
WHEEL
Wheel band thickness
20 mm0,79 in
Max wheel diameter
200 mm7,87 in
Hole diameter
31,75 mm1,25 in
EXTRA
Total power supply
3 Kw
Machine total weight
1633 Kg
Digital read out (DRO)
si
Filtration unit
SI
Floor space
2350X1050X1650 mm92,52X41,34X64,96 in
