Technical specifications
Metric
Imperial
WORKING CAPACITY
Longitudinal (X)
950 mm37,40 in
Vertical (Z)
550 mm21,65 in
Max grinding lenght
900 mm35,43 in
Max grinding width
600 mm23,62 in
Spindle nose axis - table distance
600 mm23,62 in
TABLE
Cross speed
0-30
MAGNETIC TABLE
Available upon request
Yes
FEEDS
Automatic Vertical
0,005-0,03 mm/min0,0002-0,0012 ipm
WHEEL SPINDLE
Spindle power
8 Kw
Rotating speed
1400 Rpm
WHEEL
Wheel band thickness
50 mm1,97 in
Max wheel diameter
400 mm15,75 in
Hole diameter
127 mm5,00 in
EXTRA
Machine total weight
4400 Kg
Electrical drawings
Yes
Available in stock
SI
Available under power
SI
Tooling included
PIANO MAGNETICO
Floor space
3000X2400X2000 mm118,11X94,49X78,74 in
