Category
Grinding Machine
Type
Surface
Made
Model
T110.60 CNC
Capacity
1220x600x600 mm48,03x23,62x23,62 in

Technical specifications

Metric Imperial
WORKING CAPACITY
Spindle nose axis - table distance
700 mm27,56 in
Longitudinal (X)
1220 mm48,03 in
Vertical (Z)
600 mm23,62 in
Cross Table (Y)
600 mm23,62 in
TABLE
Surface
1100x500 mm43,31x19,69 in
WHEEL
Wheel band thickness
75 mm2,95 in
Max wheel diameter
400 mm15,75 in
Hole diameter
127 mm5,00 in
WHEEL SPINDLE
Spindle power
3,7 Kw
CNC
CNC
SI
EXTRA
Machine total weight
6500 Kg
Total power supply
≈8 Kw
Automatic dresser
Yes
Filtration unit
SI
CE Certification
Yes
The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy cannot be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!
