Category
Boring Machine
Type
Mobile Column
Made
Model
PRECIRAM 2
Capacity
10500x2600x600+700 mm413,39x102,36x23,62+27,56 in
Technical specifications
Metric
Imperial
WORKING CAPACITY
Quill (W)
700 mm27,56 in
Cross RAM (Z)
600 mm23,62 in
Vertical (Y)
2600 mm102,36 in
Longitudinal (X)
10500 mm413,39 in
FEEDS
Rapid X
15 m/min590,55 ipm
W
8 m/min314,96 ipm
Z
8 m/min314,96 ipm
Y
8 m/min314,96 ipm
X
8 m/min314,96 ipm
Rapid W
15 m/min590,55 ipm
Rapid Z
15 m/min590,55 ipm
Rapid Y
15 m/min590,55 ipm
SPINDLE
Taper
ISO50
Rotating speed
0-1500 Rpm
Spindle power
64,5 Kw
Quill diameter
160 mm6,30 in
CNC
CNC
SIEMENS SINUMERIK 840DSL
ATC
Tool taper
ISO50
Positions
64
PICK UP STATION FOR HEADS
Positions
2
HEAD 1
Type
testa sottosquadra
Max power
64 Kw
Max speed
1500 Rpm
EXTRA
Chip conveyor
si
Filtration unit
si
Chiller
si
Floor space
15500x6500x5500 mm610,24x255,91x216,54 in
Electrical drawings
Yes
Maintenance & Use books
Yes
Availability
pronta consegna
Available in stock
si
Available under power
no
Mobile operator platform
si
Workpiece touch probe
si
