Boring Machine
Type
Mobile Column
Made

FPT

Model
M-ARX + AREA M200
Capacity
20000x3000x1200+500 mm787,40x118,11x47,24+19,69 in
FPT M-ARX + AREA M200
All the machines are available subject to prior sale
Gallery - 8 photos
Gallery - 8 photos
Gallery - 8 photos
Gallery - 8 photos
Gallery - 8 photos
Gallery - 8 photos
Gallery - 8 photos
Gallery - 8 photos
Data sheet

Technical specifications

Metric Imperial
WORKING CAPACITY (SECOND COLUMN)
Cross RAM (Z)
1200 mm47,24 in
Longitudinal (X)
20000 mm787,40 in
Vertical (Y)
2500 mm98,43 in
WORKING CAPACITY
Longitudinal (X)
20000x3000x1200+600 mm787,40x118,11x47,24+23,62 in
Vertical (Y)
3000 mm118,11 in
Cross RAM (Z)
1200 mm47,24 in
Quill (W)
600 mm23,62 in
CNC
CNC
Heidenhain iTNC530
SPINDLE
Spindle power
37/46 Kw
Gearbox
4-190/190-2500
Rotating speed
2500 Rpm
Torque
2815 Nm
Taper
ISO50
FEEDS
Rapid X
12 m/min472,44 ipm
Rapid Y
12 m/min472,44 ipm
Rapid Z
12 m/min472,44 ipm
X
4 m/min157,48 ipm
Y
4 m/min157,48 ipm
Z
4 m/min157,48 ipm
ATC
Positions
30
FIXING TABLE
Floorspace (LxWxH)
22000x3000 mm866,14x118,11 in
