Category
Machining Centre
Type
Vertical moving mast
Made

FAMUP-OMZ

Model
COBO
Capacity
3000x600x500 mm118,11x23,62x19,69 in
FAMUP-OMZ COBO
All the machines are available subject to prior sale
Gallery - 2 photos
Gallery - 2 photos
Data sheet

Technical specifications

Metric Imperial
WORKING CAPACITY
Longitudinal (X)
3000 mm118,11 in
Vertical (Y)
600 mm23,62 in
Cross (Z)
500 mm19,69 in
Notes
Predisposizione 4° asse, Tavola 3450x600mm
CNC
CNC
SELCA 3045D
FEEDS
Rapid X
24 m/min944,88 ipm
Rapid Y
24 m/min944,88 ipm
Rapid Z
24 m/min944,88 ipm
X
10 m/min393,70 ipm
Y
10 m/min393,70 ipm
Z
10 m/min393,70 ipm
ATC
Positions
30
Max tool diameter
100 mm3,94 in
Max diam with free adiacent space
150 mm5,91 in
Max tool lenght
250 mm9,84 in
Max tool weight
7 Kg
SPINDLE
Spindle power
11 Kw
Rotating speed
40-8000 Rpm
Taper
BT40
Notes
Refrigerazione ad alta pressione
EXTRA
Machine total weight
11000 Kg
Chip conveyor
sì
Total power supply
24 Kw
Table
3450x600mm
