Category
Machining Centre
Type
Vertical
Made
Model
AV166
Capacity
1200x600x600 mm47,24x23,62x23,62 in

Technical specifications

Metric Imperial
WORKING CAPACITY
Longitudinal (X)
1200 mm47,24 in
Cross (Y)
600 mm23,62 in
Vertical (Z)
600 mm23,62 in
SPINDLE
Rotating speed
24000 Rpm
Spindle power
30 Kw
Taper
HSK63A
ATC
Positions
24
Tool taper
HSK63A
CNC
CNC
FIDIA C1
TABLE
Floorspace (LxWxH)
1250x560 mm49,21x22,05 in
EXTRA
Electrical drawings
Yes
Maintenance & Use books
Yes
CE Certification
Yes
Housing
si
Available in stock
Yes
Machine total weight
10000 Kg
