Category
Grinding Machine
Type
Surface
Made
Model
1400
Capacity
635x203x408 mm25,00x7,99x16,06 in
Technical specifications
Metric
Imperial
WORKING CAPACITY
Spindle nose axis - table distance
83-360 mm3,27-14,17 in
Cross Table (Y)
203 mm7,99 in
Vertical (Z)
279 mm10,98 in
Longitudinal (X)
635 mm25,00 in
TABLE
Surface
610x178 mm24,02x7,01 in
Cross speed
3-21 m/min
Stroke
635 mm25,00 in
WHEEL
Hole diameter
31,75 mm1,25 in
Max wheel diameter
200 mm7,87 in
Wheel band thickness
20 mm0,79 in
WHEEL SPINDLE
Support
cuscinetti
Rotating speed
2570 Rpm
Spindle power
1,5 Kw
FEEDS
Cross
0,178-1,78 mm/min0,0070-0,0701 ipm
Automatic Vertical
0,001-0,006 mm/min0,0000-0,0002 ipm
EXTRA
Available in stock
si
Availability
pronta
Tooling included
Diaform, Piano magnetico, numerosi accessori a corredo
Floor space
2350x1054x1657 mm92,52x41,50x65,24 in
Machine total weight
1633 Kg
Total power supply
3 Kw
