Technical specifications
Metric
Imperial
WORKING CAPACITY
Min grinding diameter
0,5-50 mm0,02-1,97 in
Max plunge grinding lenght
100 mm3,94 in
Cutting speed
2000 m/sec.
OPERATOR WHEEL GROUP
Wheel power
10 Kw
Max wheel diameter
305 mm12,01 in
Wheel section
102 mm4,02 in
Wheel hole diamenter
127 mm5,00 in
CONDUCTOR WHEEL GROUP
Max wheel diameter
204 mm8,03 in
Internal wheel diamenter
80 mm3,15 in
Wheel section
102 mm4,02 in
EXTRA
Machine total weight
14500 Kg
Floor space
1400x980x1500 mm55,12x38,58x59,06 in
