Category
Drilling machine
Type
for deep holes for cylinders
Made
Model
LD 2 500 DRILLSPRINT
Capacity
2-22x500 mm0,08-0,87x19,69 in
Technical specifications
Metric
Imperial
MANDRINO FORATURA
Capacità di foratura (diam min-max)
2-22 mm0,08-0,87 in
Capacità di foratura con 2 mandrini
2-16 mm0,08-0,63 in
Max profondità foratura
500 mm19,69 in
Tipo foratura
Gundrilling
Potenza mandrino foratura
7,5 Kw
Velocità mandrino foratura
0-6000 Rpm
Working feed
0-1000 mm/min0,0000-39,3700 ipm
Spindle nose axis - table distance
200
TESTA PORTA PEZZO
Controrotazione
si
Lunghezza massima pezzo
700 mm27,56 in
Diametro massimo pezzo
72 mm2,83 in
Potenza
0,55 Kw
Velocità controrotazione
0-60 Rpm
CNC
Notes
FANUC GE-Powermate
SISTEMA REFRIGERANTE
Capacità vasca
1200 l
Capacity
66 l/min
Pressione
110 Bar
Filtration unit
20 micron
EXTRA
Numero mandrini
2
Machine weight
4500 kg
Floor space
5000x1500 mm196,85x59,06 in
Chiller
si
Chip conveyor
con separatore magnetico
Housing
integrale
